2G GSM 860 960MHz Yagi Antenna

Product Basic Information Product Name:2G GSM 860 960MHz Yagi Antenna Classic Yagi Antenna Design, specifically optimized for the 860-960MHz 2G GSM communication band. Utilizing a precisely calculated vibrator array, it achieves a high gain of 7dBi and excellent front-to-back ratio, effectively enhancing 2G signals in remote areas, basements, and shielded environments. Its all-aluminum construction is lightweight and durable, designed for long-term stable outdoor operation, making it a cost-effective solution for solving 2G signal coverage issues.   Product Basic Parameters Operating Frequency: 860-960MHz. Center frequency 910MHz, covering the entire 2GHz band. Gain: 7dBi (customizable) VSWR: ≤1.5 @ 910MHz Impedance: 50Ω Polarization: Vertical polarization Radiation Direction: Unidirectional (maximum radiation direction) Beamwidth: Horizontal 45° ± 5°, Vertical: 50° ± 5° Front-to-back Ratio >20dB. Excellent directivity Maximum Power: 100W (peak) Oscillator Material: Aluminum alloy…
