aluminum truss for stage

An aluminum truss is a modular load-bearing structure composed of aluminum profiles (mostly high-strength aluminum alloys such as 6061-T6 and 6082-T6) Pin-Lock Truss connected by welding, bolts, or pins. ​ 1. Lightweight and Easy to Operate Aluminum alloy has a density of approximately 2.7 g/cm³, only 1/3 that of steel. Under the same specifications, its weight is significantly reduced—for example, Pin-Lock Truss System for Stages a 400×400 mm aluminum truss weighs about 15–20 kg per meter, while a steel truss of the same size weighs around 40–50 kg. No large cranes are needed; 2–3 people can manually carry and assemble it, which significantly reduces labor and equipment costs. It is especially suitable for venues without heavy hoisting conditions (such as indoor exhibition halls and small theaters). 2. High Strength and Fatigue Resistance Mainstream 6061-T6 aluminum alloy has a tensile strength of ≥290 MPa and a yield strength of ≥240 MPa, while the 6082-T6 material has even highe…

Pin-Lock Truss Aluminum Alloy Stage Truss Custom Stage Round Tube Truss Demountable Stage
