JBD HIGH VOLTAGE BMS Active balance

High Voltage BMS (Master and Slave System) Master BMS (High Voltage kit) Specifications: Voltage : 102V–1000V   Persistent current Options:50A,100A, 150A,200A, 250A,300A  Choose based on the capacity and parameters of the battery cell, for example, choose 200A for a 280Ah battery High-Capacity Relay:350A rating for superior over current protection.  The benefits of choosing relays with higher rated current:1. Higher safety margin--It is ideal for relays to operate at around 80% of their rated current for a long time2.Extend the lifespan of relays--Relays with higher rated values have less contact wear, smaller arcs, lower thermal loads, and naturally longer lifespans when operating at lower currents 3. Reduce heat generation and improve system stability--Even for a 350A relay, its internal contact resistance is not too high, but when operating at 200A, the relative heat generation is relatively low, which helps with the thermal management of the entire system. Integrated Power Supply:…

48V Battert Diy Kit High Voltage BMS Prismatic Cells
