Slot-type switch DQKE3 - T54

    DQKE3-T54 Series Precision Slot Type Photoelectric Switch SHDIQI Precision Components Industrial Grade Stability Advanced Through-Beam Sensing System The DQKE3-T54 Series is a cornerstone of precision industrial automation, offering a specialized 5mm slot width for high-resolution detection. This series provides superior anti-interference performance and high-speed response capabilities, exceeding 1 KHz. The system features an integrated 940nm infrared light source and a dual-logic NO+NC output, ensuring seamless integration into both NPN and PNP control architectures. TECHNICAL DATA Standardized Performance Ratings Engineering Parameter Detailed Specification Value Model Designation DQKE3-TN54 (NPN) / DQKE3-TP54 (PNP) Sensing Mode Through-beam (Trough Type) Detection Distance (Slot Width) 5mm Min. Sensing Object Opaque body 2×0.8mm or above Power Supply Voltage 5-24V DC Current Consumption < 15mA Circuit Protection Power Reverse Polarity, Short Cir…
