Magnetic Seal Glass Lined Reactor

Magnetic Seal Glass Lined Reactor – Reactor Kettle Category This magnetic seal glass lined reactor is built for corrosion resistant and leak proof reaction service. The unit belongs to the Reactor Kettle Category. Unlike conventional agitated vessels that use a mechanical seal or packing gland on a penetrating shaft this reactor employs a magnetic drive system. The magnetic seal completely eliminates the rotating shaft penetration through the vessel wall. Torque is transmitted from an external motor to an internal impeller across a sealed containment shell. This creates a static seal arrangement rather than a dynamic one. Static seals have inherently lower leak risk compared to dynamic seals that run on a rotating shaft surface. The internal surface of this reactor is fully glass lined. All wetted parts including the vessel body and the agitator blades receive a glass coating. This surface is chemically inert to most mineral acids and organic corrosives. For applications requiring a J…
