Wideband RF Capacitor High performance

0402BB is a High Power RF Microwave Ceramic Capacitor 0402BB(.040"x.020")0402BB103KW500 Wideband RF Capacitor Product features Typical operating frequency range: 16KHz (-3dB) to 40GHz: Insertion loss: < 1dB (typical value): 50WVDC; Packaging quantity: 10Kpcs per tray. For small quantity orders, cutting and tape-wrapping options are available. 0402BB dimensions Unit: inches (millimeters) Type / Outline Capacitor Dimensions Length (L) Width (W) Thickness (T) (S) .040 ± .004   (1.016 ± 0.102) .020 ± .004   (0.508 ± 0.102) .024 (0.61)   max .016 (0.406)   min Electrical performance Item Specification Capacitance 10 nF Insulation Resistance (IR) 10¹¹ Ω min, at 25°C with rated voltage applied. Rated Voltage 50 WVDC Dielectric Withstanding Voltage (DWV) Apply 250% of rated voltage for 5 seconds. Operating Temperature Range -55°C ~ +125°C Temperature Coefficient of Capacitance (TCC) ±15% Naming method 0402BB performance curve 1 - Insertion loss and return…
